High Purity Indium Tin Oxide ITO In2O3:SnO2 Mesh Powder Customized

Product Description

Chemical Name: Indium Tin Oxide

Chemical Formula:  ITO

CAS: 50926-11-9

Purity: 99.999% (Customized)

Specifications: -60 mesh powder.

High-Purity Indium Tin Oxide (ITO) is an important transparent conductive oxide widely used in the electronics and optoelectronics fields. Known for its excellent conductivity and transparency, ITO is commonly utilized in the manufacturing of various optoelectronic devices, such as touch screens, liquid crystal displays (LCDs), and solar cells.

Physical and Chemical Properties

- Appearance: High-purity indium tin oxide typically appears as a transparent or light yellow film or powder, easy to handle and apply.

- Conductivity: It exhibits good electrical conductivity, effectively conducting electricity at room temperature.

- Transparency: ITO has high optical transmittance in the visible light range, making it suitable for various optoelectronic applications.

- Chemical Stability: It possesses good chemical stability, suitable for use in a variety of environments.

Applications

The main applications of high-purity indium tin oxide include:

1. Transparent Conductive Films:

   - ITO is widely used in touch screens, LCDs, and OLED displays as a transparent conductive layer.

2. Solar Cells:

   - In thin-film solar cells, ITO serves as an electrode material, effectively collecting the current generated by photovoltaic conversion.

3. Gas Sensors:

   - ITO is used in the manufacture of gas sensors due to its excellent conductivity and reactivity, making it suitable for detecting harmful gases.

4. Thin-Film Transistors:

   - In thin-film transistors (TFTs), ITO is an important material for source and drain electrodes, widely used in display technology.

Summary

High-purity indium tin oxide, with its superior physical and chemical properties, demonstrates significant application potential across various fields. As technology continues to advance, ITO will play an important role in the development of new electronic devices and optoelectronic materials.
