Element Symbol:(La,Sr)(Al,Ta)O3
CAS:12057-27-7
Model:Sup-(La,Sr)(Al,Ta)O3
Shape:Wafer, Disc or ingot
Thickness:[N/A]
Dimension:[N/A]
(Note: Purity, shape, thickness, and dimensions can all be customized)
Strontium Tantalate Lanthanum ((La,Sr)(Al,Ta)O₃) is an oxide material known for its excellent physical and chemical properties, classified within the family of aluminates. It features a structure that incorporates strontium, tantalum, and aluminum, typically crystallizing in a cubic form. This material is widely used in electronic devices and ceramic applications due to its outstanding electrical insulation properties and thermal stability.
Note: Purity, shape, thickness, and dimensions can all be customized,Please feel free to contact us for more details.
Main Properties:
- Crystal Structure: Exhibits high crystal quality, making it suitable for high-temperature and high-frequency applications.
- Electrical Properties: Demonstrates low dielectric loss and high dielectric constant, ideal for dielectric materials.
Applications:
1. Substrate Material: Commonly used as a substrate for high-temperature superconductors and other oxide semiconductors, facilitating the growth of high-quality thin films.
2. Electronic Components: Applied in high-frequency circuits and microwave devices to enhance electrical performance.
3. Optoelectronic Devices: Serves as an excellent dielectric material in lasers and photodetectors.
Main performance parameters | |
Crystal structure | Quartet |
Crystal growth method | Czochralski technology |
Lattice constant | a=3.756Å c=12.63 Å |
Melting point(℃) | 1650 |
Density | 5.92(g/cm3) |
Hardness | 6-6.5(mohs) |
dielectric coefficient | ε=16.8 |
Size
| 10x3,10x5,10x10,15x15,,20x15,20x20, |
Ф15,Ф20,Ф1″,Ф2″,Ф2.6″ | |
Thickness | 0.5mm,1.0mm |
Polishing | Single-sided or double-sided |
Crystal orientation | <001> |
Crystal plane orientation accuracy | ±0.5° |
Edge orientation accuracy | 2°(Special requirements can reach within 1°) |
Bevel wafer | According to specific requirements, wafers with edge-oriented crystal planes inclined at a specific angle (inclination angle 1°-45°) can be processed |
Ra: | ≤5Å(5µm×5µm) |
Package | Class 100 clean bag, Class 1000 super clean room |
