Product Name: Quartz Tube Vacuum Sealer
Brand Name: SUPSEMI
Product description: Mainly used for precision cleaning in industries such as semiconductors, coating processes, PCB manufacturing, component packaging, COG processes, vacuum electronics, connectors, and relays, as well as for surface activation of plastics, rubber, metals, and ceramics, and for cleaning life science samples in teaching and experimentation.
Product Details:
The SUP-1ZF vacuum sealing equipment is simple and quick to operate, featuring a unique rotary sealing flange that allows for adjustable and displayable sealing speeds of test tubes, all without the need for manual rotation. This significantly enhances the sealing efficiency of the test tubes.
Note:Equipping a molecular vacuum pump for simultaneous use yields better results.
The equipment consists of a high-vacuum rotary sealing system, high-vacuum pipelines, an inlet, an outlet, a venting valve, and a glass test tube flange. It is used for the daily vacuum sealing of high-purity materials in universities and research laboratories; for mass sealing of test tubes in factories; and for vacuum sealing of quartz glass test tubes and borosilicate glass test tubes.
When the quartz at the test tube opening melts, it completely isolates the samples from external air, effectively protecting samples that are sensitive to air. After sealing, samples can be sintered or transported over long distances, and transferred between glove boxes. The vacuum quartz tube sealing machine offers various models, including 1-3 workstations and custom options.
Basic Parameters | |
Vacuum Leak Rate | ≦2x10-10Pa·m3/S (measured by helium mass spectrometry) |
Vacuum Degree (Ultimate) | ≦0.1Pa (mechanical pump), ≦-5Pa (molecular pump) |
Rotational Speed | 0~20 RPM adjustable (knob speed adjustment, digital display) |
Protective Gas Inlet | 6mm quick-connect (customizable) |
Vacuum Pump Connection | KF25 (can be adapted to other specifications) |
Sealable Quartz Tube Diameter | φ10~φ35, wall thickness 2mm |
Sealable Test Tube Wall Thickness | ≤2mm |
Sealable Test Tube Outer Diameter | 8mm-45mm |
Sealable Test Tube Length | ≤500mm |
Speed Display | 1~20 RPM, digital adjustable |
Power Supply | 220V±10% 50Hz |
Vacuum Diverting Valve | Yes |
Vacuum Pipeline Material | 304 stainless steel, integrated casting process |
Basic equipment and accessories:
1. SUP-1ZF Quartz Tube Vacuum Sealing Machine x1 ;
2. KF25 Vacuum Gate Valve x1;
3. KF25 Corrugated Tube x1 ;
4. KF16 Vent Valve x1 ;
5. KF16 Vacuum Mechanical Pressure Gauge x1 ;
6. Flame Gun Holder x1 ;
7. Polarizing Lens x1; High-Temperature Gloves x1 ;
8. Quartz Test Tubes x2 (with quartz columns);
9. Quartz Tube Connector x1;
10. KF16 Clamp x1 set ;
11. KF25 Clamp x2 sets;
12. φ6mm Inlet Tube x3 meters ;
13. Power Adapter x1;
14. Molecular vacuum pump x 1
